VOLUMETRIC FEEDER DATA SHEETS

Feedrate Data Flewxwall Plus

Model NumberSpiral ScrewPellet ScrewBlade ScrewFiber Screw
FW40/1(2)[7]1020 l/hr711 l/hr747 l/hr615 l/hr
FW40/5(6)711 l/hr749 l/hr787 l/hr648 l/hr
FW80/1(2)[7]7613 l/hr5984 l/hr7095 l/hron request
FW80/5(6)7613 l/hr5984 l/hr7095 l/hron request

These are theoretical values at 100 % screw filling level and motor speed. Depending on the flow characteristics the filling level may decrease to 50 %.

Feedrate Data Flexwall Classic

Model NumberSpiral ScrewPellet ScrewBlade ScrewFiber Screw
FW20-5(10)75 l/hr38 l/hr------
FW120/0(1)[2]11252 l/hr9028 l/hr10536 l/hron request
FW155/0(1)[2]25570 l/hr15550 l/hr23130 l/hr---

These are theoretical values at 100 % screw filling level and motor speed. Depending on the flow characteristics the filling level may decrease to 50 %.

Feedrate Data Single Screw

Model NumberSpiral ScrewGranules ScrewLeaf Screw
DSR28-5298 l/hr298 l/hr---
DSR67-353743 l/hr2772 l/hr1744 l/hr
DSR67B-1003743 l/hr2772 l/hr1744 l/hr
DSR103-2006980 l/hr4520 l/hr6400 l/hr

These are theoretical values at 100 % screw filling level and motor speed. Depending on the flow characteristics the filling level may decrease to 50 %.

Feedrate Data Twin Screw

Model NumberSpiral ScrewGranules ScrewLeaf Screw
------------

These are theoretical values at 100 % screw filling level and motor speed. Depending on the flow characteristics the filling level may decrease to 50 %.

Feedrate Laboratory Feeders

Model NumberDouble Spiral ScrewDouble Granules ScrewDouble Leaf ScrewDouble Concave Screw
MT-0.5---------5.6 l/hr
MT-0.5 HYD---------5.6 l/hr

These are theoretical values at 100 % screw filling level and motor speed. Depending on the flow characteristics the filling level may decrease to 50 %.

Model NumberRotary Tube
RT 1.5On demand

EMAIL

CONTACT

GRAVIMETRIC FEEDER DATA SHEETS

Feedrate Flexwall Plus Feeders

Model NumberPerformance Range
DDW-FW80-1-7610 l/hr
DDW-FW80-2-7610 l/hr
DDW-FW80-5-4360 l/hr
DDW-FW80-6-7610 l/hr
DDW-FW80-7-7610 l/hr
DDW-FW40-1-1075 l/hr
DDW-FW40-2-1075 l/hr
DDW-FW40-5-615 l/hr
DDW-FW40-6-1075 l/hr
DDW-FW40-7-1075 l/hr

These are theoretical values at 100 % screw filling level and motor speed. Depending on the flow characteristics the filling level may decrease to 50 %.

Feedrate Flexwall Classic Feeders

Model NumberPerformance Range
DDW-FW20-0-38 l/hr
DDW-MS FW120-0-11250 l/hr
DDW-MS FW120-1-11250 l/hr
DDW-MS FW120-2-11250 l/hr
DDW-H33-FW120-0-11250 l/hr
DDW-H33-FW120-1-11250 l/hr
DDW-H33-FW120-2-11250 l/hr
DDW-MS FW155-0-25570 l/hr
DDW-MS FW155-1-25570 l/hr
DDW-MS FW155-2-25570 l/hr
DDW-H34-FW155-0-25570 l/hr
DDW-H34-FW155-1-25570 l/hr
DDW-H34-FW155-2-25570 l/hr

These are theoretical values at 100 % screw filling level and motor speed. Depending on the flow characteristics the filling level may decrease to 50 %.

Feedrate Data Single Screw

Model NumberPerformance Range
DDW-M DSR67-3743 l/hr
DDW-M DSR67B-3743 l/hr
DDW-H33-DSR103-7088 l/hr
DDW-MS DSR103-7088 l/hr

These are theoretical values at 100 % screw filling level and motor speed. Depending on the flow characteristics the filling level may decrease to 50 %.

EMAIL

CONTACT

GRAVIMETRIC BELT FEEDER DATA SHEETS

Feedrate Belt Feeder

Model NumberPerformance Range
DBW-G1-35020,000 l/hr
DBW-G1-60050,000 l/hr
DBW-G1-800100,000 l/hr
DBW-G1-1000150,000 l/hr

Setting range 1:20 (1: 100 with manual layer height adjustment)

EMAIL

CONTACT

GRAVIMETRIC VIBRATORY FEEDER DATA SHEETS

Feedrate Vibratory Feeder

Model NumberPerformance Range
DDW-MD3 DVT45-15450 l/hr
DDW-MS3 DVT45-15450 l/hr
DDW-MD5 (6) -DVT60-401000 l/hr
DDW-MS5 (6) -DVT60-401000 l/hr
DDW-MD6 DVT120-903000 l/hr
DDW-MS6 DVT120-903000 l/hr
DDW-MD6 DVT200-2006500 l/hr
DDW-MS6 DVT200-2006500 l/hr

Reference medium for performance data: plastic granulate, free flowing, bulk density 0.5 kg / dm³, particle size 4 mm. With other media, corresponding reductions in performance must be taken into account.

EMAIL

CONTACT

GAIN IN WEIGHT DATA SHEETS

MicroBatch Scale

Model NumberVolume of BowlMax Batch Weight
MB22 litre4.0 kg
MB1010 litre7.5 kg
MB5050 litre55.0 kg

EMAIL

CONTACT

GRAVIMETRIC CONTROLS

Feeder Controls

Model Number
ISC-CM plus
Congrav® CB plus
Congrav® OP 1T
Congrav® OP 15
